Installation
29
RT-SVX19A-E4
Table 24 - Electrical data - WKD/WKH Compressor motor and condenser motor
(1) At Eurovent rating conditions : Indoor return Air (27°C DB / 19°C WB) - Ambiant 35°C
(2) per motor
Table 25 - Electrical data - TKD/TKH Supply fan motor
(4) At the nominal airflow with standard drive
(5) At the nominal airflow with oversized drive when available
YKD/H
YKD/H
YKD/H
YKD/H
155
175
200
250
Indoor Fan
Nominal Airflow
(m
3
/h)
8500
9850
11210
14100
Static pressure available (4)
(Pa)
150
75
175
75
Maximum static pressure available (5)
(Pa)
350
375
450
375
Type
FC Centrifugal
FC Centrifugal
FC Centrifugal
FC Centrifugal
Diameter / Width
(in / in)
15" / 15"
15" / 15"
18" / 18"
18" / 18"
Drive type
Belt
Belt
Belt
Belt
Number
#
1
1
1
1
Motor HP (Standard/Oversized)
(kW)
2.2 / 3.0
3.0 / 4.6
3.0 / 4.6
4.6 / -
Motor Rated Amps (Standard/Oversized)
(A)
4.6 / 6.5
6.5 / 9.0
6.5 / 9.0
9 / -
Motor Locked rotor Amps (Standard/Oversized) (A)
36.4 / 57
57 / 71.9
57 / 71.9
71.9 / -
Motor RPM (Standard/Oversized)
(rpm)
1450 / 2870
2870 / 2900
2870 / 2900
2900 / -
WKD/H
WKD/H
WKD/H
125
155
200
Compressor
Number
2
2
2
Type
Scroll
Scroll
Scroll
Model
6T / 6T
7.5T /7.5T
10T / 10T
Rated Amps (1)
(A)
10.0 / 10.0
12.1 / 12.1
17.5 / 17.5
Locked rotor Amps (2)
(A)
74 / 74
79 / 79
98 / 98
Outdoor Fan
Nominal Airflow
(m
3
/h)
15300
15850
23600
Type
Axial
Axial
Axial
Diameter
(mm)
660
660
710
Drive type
Direct
Direct
Direct
Number
2
2
2
Motor HP
(kW)
0.25
0.25
0.56
Motor Rated Amps (1)
(A)
1.6
1.6
2.3
Motor Locked rotor Amps (2)
(A)
3.8
3.8
5.8
Motor RPM
(rpm)
925
925
950
