6-1
6. INSTALLATION PROCEDURE
EO1-33006
6.1 INSTALLING THE SUPPLY HOLDER UNIT
6.1 INSTALLING THE SUPPLY HOLDER UNIT
Fig. 6-2
Power Cord
Serial Interface Cable
(RS-232C)
WARNING!
Turn the POWER SWITCH to OFF before connecting the power cord or cables.
Fit the two studs on the bottom of the printer into the holes in the supply holder unit.
6.2 CONNECTING THE POWER CORD AND CABLES
Fig. 6-1
WARNING!
Turn the power OFF before installing the supply holder unit.
Supply Holder Unit
Parallel Interface Cable
(Centronics)
