93 0000h X Hardware reset result
94 0000h
F
V
Current AAM value
15-8 Vendor’s recommended AAM value
7-0 Current AAM value
95-99 0000h Reserved
100-103 XXXXh X Total Number of User Addressable Logical Sectors for 48-bit commands (QWord)
104-105 0000h Reserved
106 4000h
F
F
F
F
F
Physical sector size / logical sector size
15 Shall be cleared to zero
14 Shall be set to one
13 1 = Device has multiple logical sectors per physical sector
12 1 = Device Logical Sector longer than 256 Words
11-4 Reserved
3-0 2x logical sectors per physical sector
107-118 0000h Reserved
119 4000h
F
F
F
F
F
F
F
Commands and feature sets supported (Continued from words 84:82)
15 Shall be cleared to zero
14 Shall be set to one
13-6 Reserved
5 1= The Free-fall Control feature set is supported
4 1 = The DOWNLOAD MICROCODE command with mode 3 is supported
3 1 = The READ LOG DMA EXT and WRITE LOG DMA EXT commands are supported
2 1 = The WRITE UNCORRECTABLE EXT command is supported
1 1 = The Write-Read-Verify feature set is supported
0 Reserved for DDT
120 4000h
F
F
V
F
F
F
V
Commands and feature sets supported or enabled (Continued from words 87:85)
15 Shall be cleared to zero
14 Shall be set to one
13-6 Reserved
5 1= The Free-fall Control feature set is enabled
4 1 = The DOWNLOAD MICROCODE command with mode 3 is supported
3 1 = The READ LOG DMA EXT and WRITE LOG DMA EXT commands are supported
2 1 = The WRITE UNCORRECTABLE EXT command is supported
1 1 = The Write-Read-Verify feature set is enabled
0 Reserved for DDT
121-126 0000h Reserved for expended supported and enabled settings
127 0000h X Obsolete
