2.5” Solid State Disk
Transcend Information Inc.
V2.2
20
50
4000h
F
F
X
F
Capabilities
15 Shall be cleared to zero.
14 Shall be set to one.
13-2 Reserved.
1 Obsolete
0 Shall be set to one to indicate a device specific Standby timer value minimum.
51
0000h
F
15-8 PIO data transfer cycle timing mode
7-0 Reserved
52
0000h
X
Obsolete
53
0007h
F
F
F
X
15-3 Reserved
2 1 = the fields reported in word 88 are valid
0 = the fields reported in word 88 are not valid
1 1 = the fields reported in words 70:64 are valid
0 = the fields reported in words 70:64 are not valid
0 1 = the fields reported in words 58:54 are valid
0 = the fields reported in words 58:54 are not valid
54
XXXXh
X
Number of current cylinders
55
00XXh
X
Number of current heads
56
XXXXh
X
Number of current sector per track
57-58
XXXXh
X
Current capacity in sectors
59
0101h
V
V
15-9 Reserved
8 1 = Multiple sector setting is valid
7-0 xxh = Setting for number of sectors that shall be transferred per interrupt on R/W Multiple command
60-61
XXXXh
F
Total number of user addressable sectors
62
0000h
X
Obsolete
63
0007h
F
V
V
V
F
F
F
15-11 Reserved
10 1 = Multiword DMA mode 2 is selected
0 = Multiword DMA mode 2 is not selected
9 1 = Multiword DMA mode 1 is selected
0 = Multiword DMA mode 1 is not selected
8 1 = Multiword DMA mode 0 is selected
0 = Multiword DMA mode 0 is not selected
7-3 Reserved
2 1 = Multiword DMA mode 2 and below are supported
1 1 = Multiword DMA mode 1 and below are supported
0 1 = Multiword DMA mode 0 is supported
64
0003h
F
15-8 Reserved
7-0 Advanced PIO modes supported
65
0078h
F
Minimum Multiword DMA transfer cycle time per word
66
0078h
F
Manufacturer’s recommended Multiword DMA transfer cycle time
67
0078h
F
Minimum PIO transfer cycle time without flow control
68
0078h
F
Minimum PIO transfer cycle time with IORDY flow control
