HDMI • Y-Pr-Pb • RGB
Connection via HDMI or Y-Pr-PB (also see page 5 of the manual)
Your DVD recorder is preset to provide RGB and CVBS output video signal. If you connect a television
set or monitor fitted with HDMI or Y-Pr-PB (YUV) sockets you must modify the presets or else you
will not get a picture on these sockets.The following instructions are used to change the signal settings
for the sockets used.
In menu mode, select the socket by pressing the ZOOM/VIDEO OUT key on the remote control one
or more times until a menu appears.Your recorder's menu displays the following one after the other:
AUTO , 576P , 720P , 1080I , 1H YUV , RGB , Auto , 576P , …
EN
AV 2 (SAT-CABLE-DECODER)
AV 1 (TV)
HDMI OUT
COAXIAL
DIGITAL
AUDIO OUT
ANTENNA
/CABLE
IN
OUT
OUTPUT COMPONENT
VIDEO OUT
VIDEO
AUDIO
L
R
Y
Pb/Cb
Pr/Cr
auto
576p 576p
720p
1080i 1080i
1h yuv
rgb
rgb
" auto " 576p
1h yuv
! 1080i ! 720p
1
2
3
