ELECTRO-VOICE
®
X-Line
TM
Rigging Manual
0
500
1000
1500
2000
2500
3000
3500
-180
-150
-120
-90
-60
-30
0
30
60
90
120
150
180
Angle (Degrees)
Work
ing-
Loa
d Lim
it
(
lb)
0
200
400
600
800
1000
1200
1400
1600
Work
ing-
Loa
d Lim
it
(
K
g)
Figure 19c:
Xfil1 & Xfil2
Front Rigging Point Structural Ratings
Figure 19b:
Xvls, Xvlt & Xsub
Front Rigging Point Structural Ratings
37
Figure 19a:
Xvls, Xvlt, Xsub, Xfil1 & Xfil2
Rear Rigging Point Structural Ratings
Working-Load Limit
500 lb (227 kg)
At Any Angle
±
5°
MAX
-
∅
°
+
∅
°
Working-Load Limit
500 lb (227 kg)
At Any Angle
