Fp-11 & ant-fp
FP-11 & ANT-FP
Flat Panel Directional Antenna & Dual Directional Antenna
The FP-11 and ANT-FP are flat panel directional antennas. They are ideally suited for IEEE 802.11b and 802.11g wireless Local
Area Networks (LAN’s). Both panel antennas are for indoor and outdoor applications. The FP-11 is a single element directional
antenna while the ANT-FP is a dual element directional antenna with dual coax leads. The dual element feature allows the ANT-
FP antenna to be useful in operating in areas susceptible to the affects of multi-path interference. The FP-11 and ANT-FP are
provided with TNC reverse polarity connectors.
2.4 GHz ISM Band
IEEE 802.11b and 802.11g Superior performance
Light weight
Durable UV-stable, UL flame rated radome
Low loss solid brass elements
Can be installed for either vertical or horizontal polarization
Optional mounting brackets available
Indoor or Outdoor use
Features
