Trane GEV - Manual (Page 8)

R
General Data
Air-to-Refrigerant Coils
WSHP-PRC003-EN 8
Working Pressure 425
Tubes High 14
Tubes Deep 2
No. of Circuits 1
Finned vol. (in/mm)
(H x W x D) 14 x 16 x 1.734
356 x 406 x 44
Coil Surface Area (Ft2) 1.56
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 14
Tubes Deep 3
No. of Circuits 2
Finned vol. (in/mm)
(h,w,d) 14 x 16 x 2.598
356 x 406 x 66
Coil Surface Area (Ft2) 1.56
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 16
Tubes Deep 4
No. of Circuits 4
Finned vol. (in/mm)
(h,w,d) 16 x 19 x 3.464
406 x 483 x 88
Coil Surface Area (Ft2) 2.11
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 21
Tubes Deep 4
No. of Circuits 4
Finned vol. (in/mm)
(h,w,d) 21 x 16 x 3.464
533 x 406 x 88
Coil Surface Area (Ft2) 2.33
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 18
Tubes Deep 4
No. of Circuits 6
Finned vol. (in/mm)
(h,w,d) 18 x 21 x 3.464
457 x 533 x 88
Coil Surface Area (Ft2) 2.63
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 20
Tubes Deep 4
No. of Circuits 8
Finned vol. (in/mm)
(h,w,d) 20 x 29 x 3.464
508 x 737 x 88
Coil Surface Area (Ft2) 4.03
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 24
Tubes Deep 4
No. of Circuits 8
Finned vol. (h,w,d)
24 x 25 x 3.464
610 x 635 x 88
Coil Surface Area (Ft2) 4.17
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 14
Tubes Deep 3
No. of Circuits 1
Finned vol. (in/mm)
(h,w,d) 14 x 16 x 2.598
356 x 406 x 66
Coil Surface Area (Ft2) 1.56
Fins Per Inch 12
Tube Material Copper
Tube OD (in/mm) 3/8 / 10
Wall Thickness 0.014
Return Bends Copper
Table G9: GEH/GEV 006
Table G10: GEH/GEV 009
Table G11: GEH/GEV 012
Table G12: GEH 015, 018, 024 Table G16: GEV 042, 048
Table G15: GEH 042, 048
Table G14: GEH/GEV 030, 036
Table G13: GEV 015, 018, 024, 030
