General Data
WSHP-PRC003-EN
R
7
Model GEV 072 090 120 150 180
Unit Size (in/mm)
Length x Height x Depth
42 x 62-5/8 x 36-1/4
1067 x 1591 x 921
42 x 62-5/8 x 36-1/4
1067 x 1591 x 921
42 x 62-5/8 x 36-1/4
1067 x 1591 x 921
81-5/8 x 68 x 36-1/4
2073 x 1727 x 921
81-5/8 x 68 x 36-1/4
2073 x 1727 x 921
Compressor Type Reciprocating (2) Reciprocating (2) Scroll (2) Scroll (2) Scroll (2)
Approx. weight
with pallet/without pallet (lbs/kg)
617 / 577
280 / 262 648 / 608
294 / 276 861 / 821
391 / 373 1215 / 1170
552 / 531
1225 / 1180
556 / 536
Filter Size (nominal in/mm)
19-5/8 x 19-5/8 (4)
498 x 498 (4)
19-5/8 x 19-5/8 (4)
498 x 498 (4)
19-5/8 x 19-5/8 (4)
498 x 498 (4)
19-5/8 x 24-5/8 (6)
498 x 625 (6)
19-5/8 x 24-5/8 (6)
498 x 625 (6)
Blower Wheel (in/mm)
(Direct Drive)
12.625 x 12.625
321 x 321
12.625 x 12.625
321 x 321
12.625 x 12.625
321 x 321
15 x 15
381 x 381
15 x 15
381 x 381
Water in/out (FPT) (in/mm) 1-1/4 / 32 1-1/4 / 32 1-1/2 / 38 1-1/2 / 38 1-1/2 / 38
Condensate size (NPTI) (in/mm) 3/4 / 19 3/4 / 19 3/4 / 19 3/4 / 19 3/4 / 19
Model GEH 240
Unit Size (in/mm)
Length x Height x Depth
81-5/8 x 68 x 36-1/4
2073 x 1727 x 921
Compressor Type Scroll (2)
Approx. weight
with pallet/without pallet (lbs/kg)
1615 / 1580
733 / 717
Filter Size (nominal in/mm)
19-5/8 x 24-5/8 (6)
498 x 625 (6)
Blower Wheel (in/mm) (Direct Drive)
(Regular / High Static)
15 x 11 (2) / 12.625 x 12.625 (2)
381 x 279 (2) / 321 x 321 (2)
Water in/out (FPT) (in/mm) 2 / 51
Condensate size (NPTI) (in/mm) 3/4 / 19
Table G7: General Data - GEV 072 to 180
Table G8: General Data - GEH 240
