Telenetics Sunrise Series Modular Nest User Manual
Page 25
Part No. TEL–09949, Rev A
June 2001
Pre-Installation Information and Activities
Page 25 of 34
There are two ways to determine your modem’s software revision number.
From the modem front panel:
1) Press the appropriate front panel control key (from your location in the
configuration menu structure) until the following (for example) appears:
Data 9600 T/D?
2) Press
until the Operating Status appears (for example):
DTE 19.2 RELIABL
3) Press
until
the
following
appears:
Display Modem ID
4) Press .
The
following
appears:
SWPart=xxxxxxxx
The rightmost two digits indicate the software revision level. Ensure that they are
“30” (meaning software revision level 3.0) or higher.
Using an AT Command:
Enter AT&IO from the control terminal. The 8-digit software part number appears.
The software revision number is indicated by the rightmost two digits.
If a stand-alone modem is located between a Network Manager and a card modem,
software revision levels are not an issue. Figure 13 illustrates this condition.
Figure 13. Daisy-Chaining NC Ports: Stand-Alone Between Network
Manager and Enclosure
OUT IN
NC
Network
Manager
326X Series Modem Card in Enclosure
(Must Have Revision 3.0 Software or Higher)
326X Series
Stand-alone Modem
OUT
IN
NC
