SIM Card - Subscriber Identity Module
Static DNS - Static Domain Naming System
TCP - Transmission Control Protocol
UDP - User Datagram Protocol
UMTS - Universal Mobile Telecommunications System (aka 3GSM).
USB A Host - Universal Serial Bus type A host connector. (The “USB-in” connector on a
computer.)
USB B Device - Universal Serial Bus type B device connector. (The “USB-out” connector on
the SX7.)
WINS - Windows Internet Name Service
Wi PATH - Wireless Premise Access Transport Hub
Wireless WAN - Wireless Wide Area Network. This provides data and Internet access over a
GSM cellular network.
SX7 Connections: An Overview
WiPATH SX7
Rear Panel View and Connectors
Antenna Antenna
Power Switch
Power Input
Ethernet
USB
(Type A)
(inactive / future use)
USB
(Type B)
Phone
(SX7T only)
Phone/Fax
(SX7T only)
