User’s Manual
2-5
L500/L505/L500D/L505D
Battery safety lock
Slide this latch into its “Unlock” position in order
to release the battery pack and prepare for
removal.
Battery release latch
Slide and hold this latch into its “Unlock” position
in order to release the battery pack.
For more detailed information on removing the
battery pack please refer to Chapter 6,
.
Cooling vents
The computer’s cooling vents help keep the
processor from overheating.
Memory module
slots
The memory module slots are located here. The
memory module slots allow for the installation,
replacement and removal of additional memory
modules. Please refer to the
section in Chapter 8,
for more information.
Hard disk drive
The hard disk drive contains the main storage for
the computer. Disk size varies depending on the
model purchased.
