07.07 IF IN DOUBT ABOUT ELECTRICAL INSTALLATION,
CONSULT A LICENSED ELECTRICIAN!
ASSEMBLY INSTRUCTIONS FOR 29232-22
Fixture body
Cap
Leaves (a)
Loop with leaves
Stem
Glass
Tree
1. Before beginning the assembly, carefully unpack and identify all parts referring to the illustration.
2. Turn power to the installation point OFF.
3. Unravel the supply power and ground wires and pass the holes of cap, leaves (a) and tree.
4. Place cap and leaves (a) over the protruding nipple, and secure with tree.
5. Attach both ends of stem to the hooks of fixture body and loop with leaves.
6. Thread the nipple into the coupling at the bottom of fixture body.
7. Locate cover and leaves (b) carefully, and place them over the nipple, secure with finial.
8. Install proper bulbs (not provided) to each socket referring to the markings and labels on fixture
for maximum wattage.
9. Place glass over each socket.
10. Restore power to the installation point ON. Retain this sheet for future reference.
