600X CompactFlash Card

Transcend Information Inc.

V1.0

73




Idle - 97h or E3h

This command causes the CompactFlash Storage Card to set BSY, enter the Idle mode, clear BSY and
generate an interrupt. If the sector count is non-zero, it is interpreted as a timer count with each count being 5
milliseconds and the automatic power down mode is enabled. If the sector count is zero, the automatic power
down mode is disabled. Note that this time base (5 msec) is different from the ATA specification.

Bit ->

7

6

5

4

3

2

1

0

Command (7)

97h or E3h

C/D/H (6)

X

Drive

X

Cyl High (5)

X

Cyl Low (4)

X

Sec Num (3)

X

Sec Cnt (2)

Timer Count (5 msec increments)

Feature (1)

X

Idle Immediate - 95h or E1h

This command causes the CompactFlash Storage Card to set BSY, enter the Idle mode, clear BSY and
generate an interrupt.

Bit ->

7

6

5

4

3

2

1

0

Command (7)

95h or E1h

C/D/H (6)

X

Drive

X

Cyl High (5)

X

Cyl Low (4)

X

Sec Num (3)

X

Sec Cnt (2)

X

Feature (1)

X

Initialize Drive Parameters - 91h

This command enables the host to set the number of sectors per track and the number of heads per cylinder.
Only the Sector Count and the Card/Drive/Head registers are used by this command.

Bit ->

7

6

5

4

3

2

1

0

Command (7)

91h

C/D/H (6)

X

0

X

Drive

Max Head (no. of heads-1)

Cyl High (5)

X

Cyl Low (4)

X

Sec Num (3)

X
