600X CompactFlash Card
Transcend Information Inc.
V1.0
72
Bits 8-6: Maximum PC Card I/O UDMA timing mode supported Indicates the Maximum PC Card I/O UDMA
timing mode supported by the card when bit 15 is set.
Value Maximum PC Card I/O UDMA timing mode Supported
0 PC Card I/O UDMA mode 0 supported
1 PC Card I/O UDMA mode 1 supported
2 PC Card I/O UDMA mode 2 supported
3 PC Card I/O UDMA mode 3 supported
4 PC Card I/O UDMA mode 4 supported
5 PC Card I/O UDMA mode 5 supported
6 PC Card I/O UDMA mode 6 supported
7 Reserved
Bits 11-9: Maximum PC Card Memory UDMA timing mode supported Indicates the Maximum PC Card
Memory UDMA timing mode supported by the card when bit 15 is set.
Value Maximum PC Card Memory UDMA timing mode Supported
0 PC Card Memory UDMA mode 0 supported
1 PC Card Memory UDMA mode 1 supported
2 PC Card Memory UDMA mode 2 supported
3 PC Card Memory UDMA mode 3 supported
4 PC Card Memory UDMA mode 4 supported
5 PC Card Memory UDMA mode 5 supported
6 PC Card Memory UDMA mode 6 supported
7 Reserved
Bits 14-12: PC Card Memory or I/O UDMA timing mode selectedIndicates the PC Card Memory or I/O UDMA
timing mode selected by the card.
Value PC Card Memory or I/O UDMA timing mode Selected
0 PC Card I/O UDMA mode 0 selected
1 PC Card I/O UDMA mode 1 selected
2 PC Card I/O UDMA mode 2 selected
3 PC Card I/O UDMA mode 3 selected
4 PC Card I/O UDMA mode 4 selected
5 PC Card I/O UDMA mode 5 selected
6 PC Card I/O UDMA mode 6 selected
7 Reserved
Bit 15: PC Card Memory and IO Modes Supported
This bit, when set, indicates that the PC Card UDMA support values in bits 11-6 are valid. When this bit is
cleared, PC Card Memory and IO Modes are not supported by the device
.
