600X CompactFlash Card

Transcend Information Inc.

V1.0

71

Bits 8-6: Advanced True IDE PIO Mode Selected Indicates the current True IDE PIO mode selected on the
card.

Value

Current PIO timing mode selected

0

Specified in word 64

1

PIO Mode 5

2

PIO Mode 6

3-7

Reserved

Bits 11-9: Advanced True IDE Multiword DMA Mode Selected Indicates the current True IDE Multiword
DMA Mode Selected on the card.

Value

Current Multiword DMA timing mode selected

0

Specified in word 63

1

Multiword DMA Mode 3

2

Multiword DMA Mode 4

3-7

Reserved

Bits 15-12 are reserved.

Word 164: CF Advanced PCMCIA I/O and Memory Timing Modes Capabilities and Settings

This word describes the capabilities and current settings for CFA defined advanced timing modes using
the Memory and PCMCIA I/O interface.

Notice: The use of PCMCIA I/O or Memory modes that are 100ns or faster impose significant

restrictions on the implementation of the host:
Additional Requirements for CF Advanced Timing Modes.

Bits 2-0: Maximum Advanced PCMCIA I/O Mode Support Indicates the maximum I/O timing mode
supported by the card.

Value

Maximum PCMCIA IO timing mode Supported

0

255ns Cycle PCMCIA I/O Mode

1

120ns Cycle PCMCIA I/O Mode

2

100ns Cycle PCMCIA I/O Mode

3

80ns Cycle PCMCIA I/O Mode

4-7

Reserved

Bits 5-3: Maximum Memory timing mode supported
Indicates the Maximum Memory timing mode supported by the card.

Value

Maximum Memory timing mode Supported

0

250ns Cycle Memory Mode

1

120ns Cycle Memory Mode

2

100ns Cycle Memory Mode

3

80ns Cycle Memory Mode

4-7

Reserved
