PARTS INFORMATION
[email protected] Page 5
TBL-505
ENGINE, MUFFLER, AIR CLEANER, FUEL SYSTEM • FIGURE 2
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
2-2 99011050161 SCREW,5X16 4
2-3 99210050012 WASHER,S,5 4
2-4 99201050011 WASHER,5 4
2-6 7370500420 GASKET,MUFFLER 1
2-7 70505008900 MUFFLER,ASS'Y 1
2-8 71905008800 PIPE,MUFFLER 1
2-9 73205008200 ARRESTER,SPARK 1
2-10 7510500820 GASKET,TAIL PIPE 1
2-11 72105008801 PIPE,TAIL 1
2-12 99210040012 WASHER,S,4 2
2-13 99011040101 SCREW,4X10 2
2-14 75105004212 GASKET,MUFFLER 2
2-15 99201080011 WASHER,8 2
2-16 75005004201 BOLT,SPECIAL 2
2-17 99201060011 WASHER,6 1
2-18 99210060012 WASHER,S,6 1
2-19 99011060121 SCREW,6X12 1
2-20 99011050201 SCREW,MX20 2
2-21 99210050012 WASHER,S,5 2
2-22 99201050011 WASHER,5 2
2-23 99011060201 SCREW,6X20 1
2-24 99210060012 WASHER,S,6 1
2-25 99201060011 WASHER,6 1
2-26 73805015200 PROTECTOR,MUFFLER 1
2-27 99011060101 SCREW,6X10 1
2-28 99210060012 WASHER,S,6 1
2-30 01605004200 SHROUD,CYLINDER 1
2-36 4030501521 GASKET,INSULATOR 1 R203651~
2-37 40405015801 INSULATOR,CARBURETOR 1 ~R203650
2-37 4040502480 INSULATOR,CARB. (CA) 1 R203651~
2-38 99201050011 WASHER,5 2
2-39 99210050012 WASHER,S,5 2
2-40 99011050251 SCREW,5X25 2
2-41 4020174020 GASKET,CARBURETOR 1 ~R203650
2-41 4020602K21 GASKET,CARBURETOR 1 R203651~
2-42 87805015200 BRACKET 1 ~R203650
2-44 99101060013 NUT,6 1
2-45 89401401201 RECEIVER,OUTER 1
2-46 44225016801 PUMP,PRIMING 1 ~R203650
