PARTS INFORMATION
[email protected] Page 3
TBL-505
ENGINE / CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-59 99011050221 SCREW,5X22 2
1-61 19505015201 COVER,COIL 1
1-62 99210050012 WASHER,S,5 4
1-63 99011050101 SCREW,5X10 4
1-66 16721519802 COIL,IGNITION 1
1-67 99201040011 WASHER,4 2
1-68 99210040012 WASHER,S,4 2
1-69 99011040151 SCREW,4X15 2
1-71 99210060012 WASHER,S,6 4
1-72 99011060351 SCREW,6X35 4
1-76 15521519800 ROTOR,MAGNETO 1 ~N013860
1-76 1552152680 ROTOR,MAGNETO 1 N013861~
1-77 99200100011 WASHER,10 1
1-79 99111100011 NUT,10 1
1-81 99011050151 SCREW,5X15 6
1-82 99210050012 WASHER,S,5 6
1-83 99201050011 WASHER,5 6
1-84 SB-455 SHORT BLOCK,TBL-455/500/505 1 ~R203650
1-84 SB-4610 SHORT BLOCK,TBL-460,505C 1 R203651~
