PARTS INFORMATION
[email protected] Page 2
TBL-505
ENGINE / CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-1 15711666900 CAP, SPARK PLUG ASSEMBLY 1
1-2 01802233200 PLUG,SPARK 1
1-3 0020503220 CYLINDER 1 R203951~ CARB Approved units
1-6 99101060011 NUT,6 4
1-7 99210060012 WASHER,S,6 4
1-8 00205015201 CYLINDER 1 ~R203650
1-8 0020502421 CYLINDER 1 R203651~
1-9 01702100202 GASKET,CYLINDER 1
1-10 04105000200 RING,PISTON 2
1-11 03105004810 PISTON 1
1-12 0370100020 PIN,PISTON 1
1-13 03905004200 CIRCLIP,PISTON PIN 2
1-16 04605004831 CRANKSHAFT 1
1-17 99962101004 BEARING,NEEDLE,F1010B 1
1-18 06802000200 KEY,WOODRUFF,3X13X5 1
1-19 07010700200 WASHER,CRANKSHAFT 2
1-20 07111109200 SHIM,17.7X23X.05 1
1-20 07111109210 SHIM,17.7X23X.10 1
1-20 07111109220 SHIM,17.7X23X.15 1 Shims are "as needed to obtain correct
1-20 07111109230 SHIM,17.7X23X.20 1 c/s side clearance.
1-20 07111109240 SHIM,17.7X23X.30 1
1-21 99355050000 RING,STOP,5 1 Q234211~
1-22 7880162V20 PAWL,STARTER 1 Q234211~
1-24 7900162V200 SPRING,PAWL,STARTER 1 Q234211~
1-26 0720503190 CRANKCASE ASSY 1 Includes bearings,seals,& gaskets
1-27 99961630312 BALL BEARING #6303 2
1-28 99966173000 SEAL,OIL,#17307 2
1-29 09005004211 GASKET,CRANKCASE 1
1-30 10012000200 STUD,6X26 4
1-36-1 79805015200 PULLEY,STARTER 1 ~Q234210
1-36 7980422090 PAWL, STARTER ASSEMBLY 1 Q234211~
1-37 99111100013 NUT,10 1
1-41 66505004201 PLATE,CASE 1
1-43 99210050012 WASHER,S,5 1
1-44 99011050101 SCREW,5X10 1
1-46 19800701201 CLAMP,CORD 1
1-47 99201050011 WASHER,5 1
1-48 99011050101 SCREW,5X10 1
1-51 2030604A202 GROMMET 1
1-56 1622151980 EXCITER 1
1-57 99200050011 WASHER,SMALL,5 2
1-58 99210050012 WASHER,S,5 2
