PARTS INFORMATION
[email protected] Page 13
TBL-505
TOOLS & OPTIONAL PARTS • FIGURE 6
Optional Fan Head
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
6-1 10131310200 PIPE,FLEXIBLE 1
6-2 10231310200 PIPE,SWIVEL 1
6-3 10331310200 PIPE,STRAIGHT,LONG 1
6-4 10431310200 PIPE,BENT 1
6-6 11031310200 CLAMP,WIRE 92 1
6-7 86420000210 SCREW DRIVER,STRAIGHT 1
6-8 8262000080 SPANNER,COMBI,17X19 1
6-9 95120000200 HANDLE,8X120 1
6-10 30531310200 PIPE,STRAIGHT,SHORT 1
6-11 11131305200 CLAMP,WIRE 78 1
6-15 27331307200 FAN HEAD 1 OPTIONAL
6-21 99161060012 NUT,WING,6 1
6-22 99201060011 WASHER,6 2
6-23 26724 HANDLE,TBL 1
6-24 99060060501 BOLT,WING 6X50 1
