POWERVS15 BP
Tannoy adopts a policy of continuous improvement and product specification is subject to change POWERVS15 BP data file // Issue: 1.06 // 15.01.08
DIMENSIONAL SKETCHES
10 INPUT
D E C T S I L E T R E T N I US
MODE LINK A 0 B LEVEL - POWER - SIGNAL - LIMIT
115-230V 500VA Max 50-60Hz
POWER
TANNOY PART 3461 0913 REPLACE ONLY WITH
T10AL 250V FUSE
RAIN OR MOISTURE
OUVRIR THIS CLASS D DIGITAL DEVICE MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS AND OPERATION SUBJECT TO CONDITIONS STATED IN THE MANUAL
THIS EQUIPMENT MUST BE EARTHED
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RISQUE DE CHOC ELECTRIQUE-NE PAS CAUTION
COMPLIES WITH PART 15 OF THE FCC RULES.
AVIS: WARNING
MODE B MODE A LPF 1 80Hz LPF 2 110Hz
665.0
[26.18"]
440.0
[17.32"]
440.0
[17.32"]
195.0
[7.68"]
40.0
[1.57"]
625.0
[24.61"]
220.0
[8.66"]
38.5
[1.52"]
40.0
[1.57"]
400.0
[15.75"]
220.0
[8.66"]
222.5
[8.76"]
195.0
[7.68"]
665.0mm
(26.18”)
195.0mm
(7.68”)
440.0mm
(17.32”)
195.0mm
(7.68”)
40.0mm
(1.57”)
625.0mm
(24.61”)
400.0mm
(15.75”)
40.0mm
(1.57”)
440.0mm
(17.32”)
222.5mm
(8.76”)
38.5mm
(1.52”)
220.0mm
(8.66”)
220.0mm
(8.66”)
