POWERVS15 BP
Tannoy adopts a policy of continuous improvement and product specification is subject to change POWERVS15 BP data file // Issue: 1.06 // 15.01.08
TECHNICAL SPECIFICATIONS
System Type Subwoofer - Bandpass
Frequency Response (-3dB) (1) 47Hz - 80kHz
Low pass flilter A on
Frequency Range (-10dB)
(1) 47Hz - 110kHz
Low pass filter B on
Frequency Response (-3dB)
(1) 37Hz - 80kHz
Low pass filter A on
Frequency Range (-10dB)
(1) 37Hz - 110kHz
Low pass filter B on
Driver Complement
1 x 380mm (15.00”)
High excursion bass driver
Crossover User selectable LPF
Rated Maximum SPL (2)
Average 124dB
Peak 130dB
Distortion
10% Full Power (15.5V)
2nd Harmonic 3rd Harmonic
40Hz 0.65% 0.67%
100Hz 3.05% 0.70%
1% Full Power (4.9V) 2nd Harmonic 3rd Harmonic
40Hz 0.13% 0.30%
100Hz 0.76% 0.24%
PSU Specifications
Input Connector Locking Neutrik Powercon
Voltage Selection Automatic (115 / 230V, 45 - 65Hz)
Type High current, high frequency switch
mode
Efficiency >90% typical
Input voltage 100v / 115v / 230v nominal +/-10%
Mains fuse External
Fuse type T10AT
Other features Automatic soft start
Enclosure 100 litre internally braced 15mm (0.62”)
birch plywood enclosure
Finish Textured black or white paint with
custom colours on request
Connectors 1 x female XLR (input)
1 male XLR (link)
1 x Neutrik Powercon
Controls & Level control
Indicators Power LED (Blue)
Signal LED (Green)
Limit LED (Red)
Full range / High pass switch (110Hz)
Power switch
Fittings 8 x M10 flying inserts
2 x recessed carry handles
Blanking plate for optional VTH pole
mount
4 x Rubber feet
Dimensions 665 x 440 x 440mm
H x W x D 26.18 x 17.32 x 17.32”
NET Weight 30kg
(66lbs)
Electronics
Maximum signal input for clip Input attenuator at minimum: +18dBu
Input attenuator at maximum: +5dBu
Output noise -105dB unweighted, referenced to
maximum output (22kHz bandwidth)
Efficiency >90% typically
Damping Factor 400 ref 8 Ohms
Distortion <0.05% @ 1kHz -3dB output
(22kHz bandwidth)
Input Impedance 5.6kOhms unbalanced
11.2kOhms balanced
Protection systems Over Current Excessive over current causes shutdown
Temperature Limiters applied
Brownout Automatic protection and recovery
Mains Inrush current limiting
Indicators 1x Limit LED
1x Signal LED
1x Power LED
Number of channels One
System Type Class D
System POWERVS15 BP Construction
8001 4310 POWERVS15 BP Black 1
8001 4311 POWERVS15 BP White 1
PART NUMBER PACKED QUANTITY COLOUR MODEL NAME
Ordering Information
Notes:
(1) Average over stated bandwidth. Measured at 1 metre on axis.
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
A full range of measurements, performance data, CLF and Ease™ Data can be
downloaded from www.tannoy.com
Full independent verification of published specifications carried out by NWAA Labs,
California can also be obtained from the downloads section of www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction
of new materials or manufacturing methods will always equal or exceed the
published specifications, which Tannoy reserves the right to alter without prior
notice. Please verify the latest specifications when dealing with critical applications.
