L1 Diagramme électrique/ Wiri ng diagram
Contrôle Bi-énergy/ Dual control ener gy CBE-EM
N
120 Vac
24 Vac
H H
V3
V2
E1
E2
T1
T2
Bi-energie/ Dual energy
Electrique/ Ele ctric
Mazout/ Oil
Relais/ Relay
COMBOMAX
E2 V2
T
T
Relais chaud ière
mazout/
Oil boiler Relay
Noir/ Black
V1
Brun/ Brown
Bleu/ Blue
B
AB
A
Electrique/ Electric
Mazout/ Oil
SPDT
Relais/ Relay
Interrupteur DPDT
Switch ON-OFF-ON
Sonde extérieur/
Outdoor sensor
Transfo
Lumière haut tarif/
High tarif light
Valve 3 voies optionnelle/
Optional 3-way valve
Cablage en usine/
Factory wiring
Cablage par l'installateur/
Wiring by others
H H V1 V2 V3 T1 T2 E1 E2
Valve 3 voies optionnelle/
Optional 3-way valve
Sonde extérieur/
Outdoor sensor
No
ir
/ B
la
c
k
B
run/ B
row
n
Ble
u
/ Bl
u
e
Lumière haut tarif/
High tarif light
Transfo
120 Vac
24 Vac
Interrupteur DPDT
Switch ON-OFF-ON
Bi-energie/ Dual energy
Electrique/ Ele ctric
Mazout/ Oil
SPDT
Relais/ Relay
Chaudière électrique/
Electric boiler
BTH/ GTH/ COMBOMAX
("E2 V2" bornier 24 Vac/
terminal E2-V2)
Chaudière mazout
Oil boiler
("T T" relais de combustion/
oil boiler burner)
