Appendix B Specifications
Trango Broadband Wireless — Atlas5010 page 45
Antennas
Integrated Antenna (for Atlas5010-INT)
Frequency range: 5250-5850 MHz
Gain:
23 dBi +/- 1 dB
Front/Back Ratio >35 dB
E-Plane Beamwidth: > 9 degrees typical
H-Plane Beamwidth: > 9 degrees typical
Polarization: Vertical and Horizontal
Port/Port Isolation: 40 dB typ
Cross Pol Rejection: 25 dB typ
VSWR: <1.7:1
Package: Alumininum backplate with plastic radome.
Dimensions: 14.6”x 14.6”x 1.58” (371mm x 371mm x 40mm)
Weight: 5.5 lbs (2.5 kg)
Azimuth/El Adjust: +/-30 degrees
Temp Range: -40 deg F to +160 deg F (-40 deg C to +60 deg C)
Wind speed operational: 100 mph (160 km/hr)
Wind speed survival :
140 mph (220 km/hr)
FCC Certified External Antennae (for Atlas5010-EXT)
Radiowaves models:
SPD4-5.2, SPD3-5.2, SPD2-5.2, SPD1-5.2
See Radiowaves, Inc. website for specifications and details.
