Appendix B
Specifications
Trango Broadband Wireless — Atlas5010
page 43
Appendix B Specifications
RF Parameters
Transmitter
RF Conducted Power:
Limits
Band 4 (US ISM):
Max: +21 dBm (6 Mbps)
5.725-5.85 GHz
Max: +19 dBm (12, 18 Mbps)
Max: +18 dBm (24, 36 Mbps)
Max: +17 dBm (48, 54 Mbps)
Min:
-4
dBm
EIRP Max:
+45 dBm High band P5010M-23-MU/RU (23 dBi panel antenna)
+56 dBm High band P5010M-EXT-MU/RU w/34 dBi 4 foot dish antenna
RF Data Rate:
6, 12, 18, 24, 36, 48, 54 MBPS User selectable
Error Correction:
FEC & ARQ
Modulation:
6 MBPS DBPSK OFDM for header, 6-54 MBPS OFDM for payload
Receiver
Receiver Sensitivity Table
Max Speed (Mbps) Sensitivity dBm
54 (45)
-73
48 (40)
-75
36 (31)
-80
24 (20)
-83
18 (16)
-86
12 (11)
-88
6 (5)
-92
Numbers in parentheses are actual max user throughput speeds
Channels of Operation
Storable Channels:
24 memory locations
Center frequency ranges:
Band 4:
5.735 to 5.835 GHz
Tuning resolution:
5 MHz increments
(US Models)
Channel 19: 5.735 GHz
-Band 4
Channel 20: 5.755 GHz
-Band 4
Channel 21: 5.775 GHz
-Band 4
Channel
22:
5.795
GHz
-Band
4
Channel
23:
5.815
GHz
-Band
4
Channel 24: 5.835 GHz
-Band 4
