Texas Instruments CDCM7005 - Manual (Page 23)

Parts List
6-4
Item QTY Reference
Designator
Footprint Part Part Number
48 7 R4, R6, R13, R15,
R62, R63, R65
smd_res_0402 100 Ω Panasonic
ERJ−2RKF1000X
49 6 R5, R8, R14, R17,
R21, R23
smd_res_0402 150 Ω Panasonic
ERJ−2RKF1500X
50 10 R25, R57, R59,
R60, R68−R71,
R74, R75
smd_res_0402 10 kΩ Panasonic
ERJ−2RKF1002X
51 2 R28, R45 smd_res_0402 NU 0 Ω Panasonic
ERJ−2GE0R00X
52 4 R29, R32, R49,
R80
smd_res_0402 NU 150 Ω Panasonic
ERJ−2RKF1500X
53 2 R38, R31 smd_res_0402 130 Ω Panasonic
ERJ−2GEJ131X
54 10 R33, R34, R41,
R42, R82,−R87 smd_res_0402 0 Ω Panasonic
ERJ−2GE0R00X
55 2 R43, R36 smd_res_0402 82 Ω Panasonic
ERJ−2GEJ820X
56 2 R37, R44 smd_res_0402 NU NU
57 2 R39, R40 smd_res_0402 62 W Panasonic
ERJ−2GEJ620X
58 2 R47, R46 smd_res_0402 NU 100 Panasonic
ERJ−2RKF1000X
59 4 R51, R64, R66,
R67
smd_res_0402 100 kΩ Panasonic
ERJ−2RKF1003X
60 1 R52 smd_res_0402 160 Ω Panasonic
ERJ−2RKF1002X
61 2 R53, R72 smd_res_0402 4.7 kΩ Panasonic
ERJ−2RKF1472X
62 3 R54−R56 smd_res_0402 750 Panasonic
ERJ−2GEJ131X
63 1 R58 smd_res_0402 NU 12K 1% Panasonic
ERJ−2RKF4121X
64 1 R61 smd_cap_0402 1.5 kΩ Panasonic
ERJ−2RKF1501X
65 1 R73 smd_res_0402 180 Ω Panasonic
ERJ−2RKF1472X
66 3 R78, R79, R81 smd_res_0402 22 Ω Panasonic
ERJ−2GEJ220X
67 2 SW2, SW1 switch_reset SW
PUSHBUTTON
KT11P3JM
68 2 TP1, TP2 testpin_30dia T POINT R Test point
69 1 U2 mbga_pt8mm_64_skt CDCM7005 Texas Instruments
CDCM7005
70 1 U3 soic14 SN74LV125 Texas Instruments
SN74LV125AD
71 1 U4 soic_round_4 NU SGA−4586 NU Sirenza SGA−4586
72 1 U5 soic8 OPA341 Texas Instruments
OPA341UA
73 1 VCXO1 VCXO_6 VCXO_6 Toyocom VCXO
74 4 MP3 STAND OFF Legs for PCB
75 4 MP2 SCREW Legs for PCB
