Selecting functions from the playback menu
Playback on TV
● To connect the cradle to a TV, use the provided AV cable.
● To play back images on a TV, use the provided AC adapter.
● Make sure that the camera’s video output signal type is the same as the TV’s
video signal type.
~
“VIDEO OUT — Selecting the video signal type” (P. 129)
● The camera’s monitor turns off automatically when the AV cable is connected to
the cradle.
● The image may appear off-center depending on the TV screen.
Turn off the TV and connect
the cradle to the TV using
the provided AV cable.
Cradle
connector
Connector
end
Turn on the TV and set it to
the video input mode. For
details on switching to the
video input mode, refer to
the TV’s instruction manual.
To the A/V OUT
jack
AV cable (provided)
To the video input (yellow)
and audio input (white)
terminals on the TV
Press
Set the mode switch to and turn
on the camera.
Turn off the camera.
Attach the camera to the cradle.
