Loading the battery – Olympus 2004 User Manual
Page 25

25
1
Getting star
ted
Loading the battery
6
7
5
3
4
1
2
1
2
Release the
latch to insert
the battery.
Open the battery/card
compartment cover.
Close the battery/
card compartment
cover.
The camera uses an Olympus lithium-ion battery (LI-20B). Do not use any other type
of battery.
● A backup battery (optional) is recommended for extended battery-powered operation.
Insert the battery with the
OLYMPUS logo face up.
Gently push the latch backwards
to lift it
3
. When you take your
finger off the latch, the latch drops
back on its own
4
. After the latch
drops back, insert the battery
5
.
Battery/Card compartment cover
Lift up the cover
6
and push down
firmly on the
section of the cover
7
to close. Closing the battery/card
compartment cover locks the latch.
Slide the battery/card compartment
cover in the direction of the arrow
1
. The cover unlocks and opens
in the direction of the arrow
2
.
Latch
