60
En
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels:
(North American)
80 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.08% (FTC)
90 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
at 1 kHz, with a maximum total harmonic
distortion of 0.7% (FTC)
100 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
(Others)
7 ch
×
130 W at 6 ohms, 1 kHz, 1 ch driven
(IEC)
Maximum Effective Output Power
(Asian)
7 ch
×
160 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power 180 W (3
Ω, Front)
160 W (4 Ω, Front)
100 W (8 Ω, Front)
THD (Total Harmonic Distortion)
(North American)
0.08% (Power Rated)
(Others)
0.08% (1 kHz, 1 W)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 k
Ω (LINE)
Output Level and Impedance
200 mV/2.2 k
Ω (REC OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB, -3 dB (DSP bypass)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
Speaker Impedance (North American) 6
Ω - 16 Ω
(Others) 4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75
Ω (Component Y)
0.7 Vp-p/75
Ω (Component P
B /C B , P R /C R )
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
FM Tuning Frequency Range
(North American) 87.5 MHz - 107.9 MHz
(European) 87.50 MHz - 108.00 MHz,
RDS
(Others) 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
(North American) 530 kHz - 1710 kHz
(Others) 522/530 kHz - 1611/1710 kHz
Preset Channel 40
Digital Tuner (North American models)
SIRIUS
Power Supply (North American) AC 120 V, 60 Hz
(European) AC 230 V, 50 Hz
(Others) AC 220 - 240 V, 50/60 Hz
Power Consumption (North American) 4.9 A
(European) 450 W
(Others) 500 W
Stand-by Power Consumption
(North American) 0.2 W
(Others) 0.3 W
Dimensions
(W
×
H
×
D)
435 mm
×
151.5 mm
×
328.5 mm
17-1/8"
Ч
5-15/16"
Ч
12-15/16"
Weight (North American)
8.6 kg (19.0 lbs.)
(Others)
9.4 kg (20.7 lbs.)
Input IN 1, IN 2, IN 3, IN 4
Output OUT
Video Resolution 1080p
Audio Format Dolby True HD, DTS Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, Deep Color,
x.v.Color, LipSync, CEC
Component IN 1, IN 2
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,
AUX
Component OUT
Composite MONITOR OUT, VCR/DVR OUT
Digital Optical: 2
Coaxial: 2
Analog BD/DVD, VCR/DVR, CBL/SAT, GAME,
TV/CD, AUX
Analog VCR/DVR, ZONE2 Line Out
Subwoofer Pre Output
1
Speaker Outputs Main (L, R, C, SL, SR, SBL, SBR)
+ ZONE2 / Front High (L, R)
Phones 1 (6.3 ø)
Mic 1
Universal Port 1
RI 1
