WOOD STUD INSTALLATION
Установка на стену с деревянными стойками
RU
Installazione su muro con montanti in legno
IT
Installatie op muur met houten dragers
NL
Montage an Holzbalken an der Wand
DE
Installation murale sur poteau de cloison en bois
FR
Instalación en pared con paneles de madera
ES
Wood Stud Wall Installation
EN
Просверлите направляющее отверстие
Trapanare il foro pilota
Boor een montagegat
Bohren Sie die Vorbohrung
Percez le trou de guidage
Realice el agujero piloto
Drill pilot hole
Wood Pilot
Pilot Hole Size
Pilot Drill Depth
1/8” inch
2” inch
4 mm
55 mm
X4
