Installer Manual
8
TECHNICAL DATA
Main Panel
Input power 16.5 V AC 25 VA via transformer
Rechargeable standby battery 12 V 4 A-Hours
Auxiliary Power 12 V DC 250 mA maximum
Bell/LS Sounder output 12 V DC 750mA maximum
Programmable output Open collector Active pull down 70mA maximum
Cabinet Dimensions: 260X218X83 mm (10.2X5.1X3.3 “)
Weight 1.84 kg (4 lb)
Main Board (dimensions / weight): 80X167 mm (3.15X6.6 “) 0.17 kg (0.37lb)
Fuse F1 Auxiliary Power 0.5 A
Fuse F2 Bell/LS Power 1 A
Fuse F3 Battery Power 2 A
Keypads
6-Zone Keypad 8-Zone Keypad
Current consumption: 18 mA typical, 30 mA maximum 18 mA typical, 30 mA maximum
Control panel
connections: 4-wire up to 300 ft (100 m) from
panel 4-wire up to 300 ft (100 m) from
panel
Dimensions: 110X130X25 mm (4.3X5.1X1 “) 110X130X25 mm (4.3X5.1X1 “)
Weight: 0.19 kg (0.42 lb) 0.19 kg (0.42 lb)
Utility Output Expansion Module
Relay Transistor
Current consumption: 10mA typical, 50mA max 10mA typical, 15mA max
Control panel connections: 4-wire up to 300 ft (100m) from panel
Contacts: 4 relays, 0.5 A, 24 V DC 4 O.C., 50 mA, 12 V DC
Dimensions: 53X85 mm (2.1X3.35 “)
Weight: 80 gr (0.18 lb)
Max. Run Length from Panel to Keypad
AWG 19 20 22 Wire
Ø (mm) 0.9 0.8 0.6
Meter 200 166 100 Length
Feet 660 547 330
Bell Loudspeaker Wiring Table (Distance in Feet)
18 19 20 22
1 0.9 0.8 0.6
AWG
Ø mm
Max.
Current mA
Feet Meter Feet Meter Feet Meter Feet Meter
100 780 238 625 190 495 151 310 95
300 260 79 208 64 165 50 103 32
650 120 37 96 30 76 23 48 15
Detectors Distance in Feet
18 19 20 22 24
1 0.9 0.8 0.6 0.5
AWG
Ø mm
Max.
Current mA
Feet Meter Feet Meter Feet Meter Feet Meter Feet Meter
20 3920 1195 3100 945 2460 750 2460 472 1550 296
30 2600 793 2060 628 1640 500 1640 314 1030 197
40 1960 597 1550 472 1230 375 1230 236 775 148
