35
Specifications (TX-8222)
Amplifier Section
Tuner Section
■
FM
■ AM
General
■
Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Rated Output Power (FTC) (North American)
All channels: 50 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08 %
Rated Output Power (IEC) (European and Australian)
2 ch
×
70 W at 4 ohms, 1 kHz, 2 ch driven
Maximum Output Power (JEITA) (Asian)
90 W at 4 ohms, 1 kHz, 2 ch driven
Dynamic Power
North American:
135 W + 135 W (2 Ω )
105 W + 105 W (4 Ω )
70 W + 70 W (8 Ω )
European and Australian:
110 W + 110 W (2 Ω )
90 W + 90 W (4 Ω )
55 W + 55 W (8 Ω )
THD (Total Harmonic
Distortion)
0.08 % (Power Rated)/ 0.08 % (1 kHz,
1 W)
Damping Factor 60 (Front, 1 kHz, 8 Ω )
Input Sensitivity and
Impedance
150 mV/ 50 k Ω (LINE)
2.5 mV/ 50 k
Ω
(PHONO MM)
Output Level and
Impedance
150 mV/ 2.2 k Ω (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB–3 dB (CD)
Tone Control ±10 dB, 100 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 Ω –16 Ω
Tuning Frequency
Range
North American: 87.5 MHz– 107.9 MHz
Others: 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo: 22.2 dBf (75 Ω IHF)
Mono: 15.2 dBf (75 Ω IHF)
Signal to Noise Ratio Stereo: 67 dB (IHF-A)
Mono: 73 dB (IHF-A)
THD Stereo: 0.5 % (1 kHz)
Mono: 0.3 % (1 kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 40 dB (1 kHz)
Tuning Frequency
Range
North American: 530 kHz–1710 kHz
Others: 522 kHz–1611 kHz
Usable Sensitivity 300 µV
Signal to Noise Ratio 40 dB
THD 0.7 %
Power Supply North American: AC 120 V, 60 Hz
European: AC 230-240 V, 50 Hz
Others: AC 230-240 V, 50Hz
Power Consumption North American: 2.1 A
European: 180 W
Others: 180 W
Standby Power
Consumption
North American: 0.2 W
Others: 0.3 W
Dimensions
(W
×
H
×
D)
435
Ч
150
Ч
332 mm
17-1/8"
Ч
5-7/8"
Ч
13-11/16"
Weight 7.5 kg
16.5 lbs.
Analog Inputs PHONO, CD, TAPE 1, TAPE 2, LINE 1,
LINE 2
Analog Outputs TAPE 1, TAPE 2
Speaker Outputs SPEAKERS A
SPEAKERS B
Phones 1
IR Input/Output 1/1
