40
En
A/V Sync
■
A/V Sync
`
0 ms to 400 ms in 10 ms steps
When using progressive scanning on your Blu-ray
Disc/DVD player, you may find that the picture and sound
are out of sync. With this setting, you can correct this by
delaying the audio signals.
To view the TV picture while setting the delay, press
ENTER.
To return to the previous screen, press RETURN.
The range of values you can adjust will depend on
whether your TV or display supports HDMI Lip Sync and
if the “LipSync” setting is set to “On” or not
(
➔
page 43).
Note
• A/V Sync is disabled when the Direct listening mode is used
with an analog input source.
Preset Name For Input Selector
■
Name
`
- - -, Blu-ray, DVD, HD DVD, VCR, DVR, Tivo,
CableSTB, SAT STB, PS3, Wii, Xbox, PC, TV, CD,
TAPE, iPod:
To reset to the default, select “- - -”.
You can enter a preset name for each individual input
selector for easy identification. When entered, the preset
name will appear on the display.
Note
• Can not set the input selector by the same name.
• This menu cannot be used for the AM, FM or USB input
selector.
Audio Selector
■
Audio Selector
`
ARC:
The audio signal from your TV tuner can be sent to
the HDMI OUT of the AV receiver.
*1
With this selection the TV’s audio can be
automatically selected as a priority among other
assignments.
`
HDMI:
This can be selected when HDMI IN has been
assigned as an input source. If both HDMI (HDMI
IN) and digital audio inputs (COAXIAL IN or
OPTICAL IN) have been assigned, HDMI input is
automatically selected as a priority.
`
COAXIAL:
This can be selected when COAXIAL IN has been
assigned as an input source. If both coaxial and
HDMI inputs have been assigned, coaxial input is
automatically selected as a priority.
`
OPTICAL:
This can be selected when OPTICAL IN has been
assigned as an input source. If both optical and
HDMI inputs have been assigned, optical input is
automatically selected as a priority.
`
Analog:
The AV receiver always outputs analog signals.
You can set priorities of audio output when there are both
digital and analog inputs.
Note
• The setting is stored individually for each input selector.
• This setting can be made only for the input source that is
assigned as HDMI IN, COAXIAL IN, or OPTICAL IN. If both
HDMI (HDMI IN) and digital audio inputs (COAXIAL IN or
OPTICAL IN) are assigned, HDMI input will be selected as a
priority by setting to “ARC” (
➔
page 42). To select the digital
audio input, see “Digital Audio (Digital Audio Input)”
(
*1
You can select “ARC” if you select the TV/CD input selector.
But you cannot select it if you’ve selected “Off” in the
“Audio Return Ch” setting (
➔
page 42).
About Audyssey Dynamic EQ
®
Audyssey Dynamic EQ solves the problem of
deteriorating sound quality as volume is decreased by
taking into account human perception and room
acoustics. Dynamic EQ selects the correct frequency
response and surround levels moment-by-moment at
any user-selected volume setting. The result is bass
response, tonal balance, and surround impression that
remain constant despite changes in volume. Dynamic
EQ combines information from incoming source levels
with actual output sound levels in the room, a
prerequisite for delivering a loudness correction
solution. Audyssey Dynamic EQ works well by itself.
However, if Audyssey 2EQ
®
is on, the two technologies
work in tandem to provide well-balanced sound for
every listener at any volume level.
About Audyssey Dynamic Volume
®
Audyssey Dynamic Volume solves the problem of large
variations in volume level between television programs,
commercials, and between the soft and loud passages of
movies. Dynamic Volume looks at the preferred volume
setting by the user and then monitors how the volume of
program material is being perceived by listeners in real
time to decide whether an adjustment is needed.
Whenever necessary, Dynamic Volume makes the
necessary rapid or gradual adjustments to maintain the
desired playback volume level while optimizing the
dynamic range. Audyssey Dynamic Volume works fine
by itself, but can also be used with
Audyssey Dynamic EQ. When both are on,
Audyssey Dynamic EQ adjusts the perceived bass
response, tonal balance, surround impression, and
dialog clarity whether watching movies, flipping
between television channels, or changing from stereo to
surround sound content, when Dynamic Volume adjusts
the volume.
