15
Specifications
Power Output Front L/R 100 W + 100 W
(8
Ω, 1 kHz, DIN)
Dynamic Power 310 W + 310 W (3
Ω, Front)
240 W + 240 W (4
Ω, Front)
130 W + 130 W (8
Ω, Front)
THD (Total Harmonic Distortion) 2 % (Power Rated) / 0.08 % (1 kHz 1 W)
Damping Factor 25 (Front, 1 kHz, 8
Ω)
Input Sensitivity and Impedance 200 mV / 50 k
Ω (LINE)
2,5 mV / 50 k
Ω (PHONO MM)
Output Level and Impedance 200 mV / 2,2 k
Ω (REC OUT)
Phono Overload 130 mV (MM 1 kHz 0,5 %)
Frequency Response 10 Hz ~ 60 kHz / +1 dB-3 dB (CD)
SN Ratio 100 dB (CD, IHF-A)
70 dB (PHONO, IHF-A)
Speaker Impedance 4
Ω ~ 16 Ω
Power Supply AC 230-240 V, 50 Hz
Power Comsumption 105 W
Dimensions (W
× H × D)
435 W
× 81,5 H × 390 D mm
17 1/8 W
× 3 3/16 H × 15 3/8 D inches
Weight 11,3 kg
24,9 lbs
Analog Inputs PHONO, TUNER, CD, LINE1, LINE2, MAIN IN
Analog Outputs LINE2
Pre Outputs 1 (L/R)
Speaker Outputs 1 (L/R)
Specifications and features are subject to change without notice.
