■ Specifications
Type of lens: G-type AF-S Zoom-NIKKOR lens with built-in CPU and
Nikon bayonet mount
Focal length: 200-400mm
Maximum aperture: f/4
Lens construction: 24 elements in 17 groups (4 ED and some Nano Crystal
Coat-deposited lens elements), as well as 1 detachable
protective glass
Picture angle: 12°20´-6°10´ with 35mm (135) format Nikon film SLR
cameras and Nikon FX format digital SLR cameras
8°-4° with Nikon DX format digital SLR cameras
9°50´-5° with IX240 system cameras
Focal length scale: 200, 250, 300, 350, 400mm
Distance information: Output to camera
Zoom control: Manually via separate zoom ring
Focusing: Nikon Internal Focusing (IF) system, autofocus using a
Silent Wave Motor; manually via separate focus ring
Vibration reduction: Lens-shift method using voice coil motors (VCMs)
Shooting distance
scale:
Graduated in meters and feet from 2 m (7 ft) to
infinity (∞)
Closest focusing
distance:
2 m (6.6 ft.) with autofocus, at all zoom settings
1.95 m (6.4 ft.) with manual focus, at all zoom settings
No. of diaphragm
blades:
9 pcs. (rounded)
Diaphragm: Fully automatic
Aperture range: f/4 to f/32
Exposure
measurement:
Via full-aperture method with cameras with CPU
interface system
Focusing limit switch: Provided; two ranges available: FULL (∞–2 m), or ∞–6 m
Tripod collar: Rotatable through 360°, lens rotating position index at
90°, only tripod collar detachable
Dimensions: Approx. 124 mm dia. x 365.5 mm extension from the
camera’s lens-mount flange with lens protective glass
attached
Approx. 124 mm dia. x 358.5 mm extension from the
camera’s lens-mount flange without lens protective glass
Weight: Approx. 3,360 g (7.4 lbs) with lens protective glass
Approx. 3,240 g (7.1 lbs) without lens protective glass
Specifications and designs are subject to change without any notice or obligation on the
part of the manufacturer.
