109
Specifications
Amplifier Section
Video Section
Tuner Section (TX-SR705 only)
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power (FTC)
All channels:
100 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08%
115 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7%
125 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz with a maximum total
harmonic distortion of 0.1%
Rated Output Power (IEC)
7 ch
u
160 W at 6 ohms, 1 kHz, 1 ch
driven
Maximum Output Power (JEITA)
7 ch
u
175 W at 6 ohms, 1 kHz, 1 ch
driven
Dynamic Power 240 W + 240 W (3 :, Front)
210 W + 210 W (4 :, Front)
120 W + 120 W (8 :, Front)
THD (Total Harmonic Distortion)
0.08% (Power Rated)
0.08% (1 kHz, 1 W)
Damping Factor 60 (Front, 1 kHz, 8 :)
Input Sensitivity and Impedance
200 mV/47 k : (LINE)
2.5 mV/47 k :, (PHONO MM)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Output Level and Impedance
200 mV/470 : (REC OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB - 3 dB (Direct mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 : - or 6 : - 16 :
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 : (Component and S-Video Y)
0.7 Vp-p/75 : (Component P
B /C B , P R /C R )
0.28 Vp-p/75 : (S-Video C)
1 Vp-p/75 : (Composite)
Component Video Frequency Response
5 Hz - 50 MHz - 3 dB
FM Tuning Frequency Range
North American: 87.5 MHz - 107.9 MHz
Others: 87.5 MHz - 108.0 MHz
AM Tuning Frequency Range
North American: 530 kHz - 1710 kHz
European: 522 kHz - 1611 kHz
Others: 522/530 kHz - 1611/1710 kHz
Preset Channel 40
Digital Tuner (North American models only):
XM, SIRIUS
Power Supply North American: AC 120 V, 60 Hz
European: AC 220 - 240 V, 50/60 Hz
Others: AC 220 - 240 V, 50/60 Hz
AC 120 V, 60 Hz
Power Consumption North American: 6.2 A
European: 600 W
Others: 600 W
Dimensions (W
u
H
u
D)
435
u
174
u
377 mm
17-1/8"
u
6-7/8"
u
14-13/16"
Weight North American: 12.9 kg (28.4 lbs.)
Others:
12.8 kg (28.2 lbs.)
12.7 kg (28.0 lbs.)
HDMI IN1, IN2, IN3
Component IN1, IN2, IN3
S-Video DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX
Composite DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX
HDMI OUT
Component OUT
S-Video MONITOR OUT, VCR/DVR
Composite MONITOR OUT, VCR/DVR
Digital Inputs Optical: 2 (Rear), 1 (Front)
Coaxial: 3
Analog Inputs DVD (MULTICHANNEL), VCR/DVR,
CBL/SAT, GAME/TV, AUX, TAPE, CD,
PHONO
Multichannel Inputs 7.1
Digital Outputs Optical: 1
Analog Outputs TAPE, VCR/DVR, ZONE2
Multichannel Pre
Outputs
7
Subwoofer Pre Output 1
Speaker Outputs FL, FR, C, SL, SR, SBL, SBR,
ZONE2 (L/R)
Phones 1
MIC Yes
RS232 1
IR Input 1
12 V Trigger Out ZONE2
