Orion Car Audio Coaxial Speaker XTR522 - Manual (Page 8)

© 2008 directed electronics—all rights reserved 7
Figure 6
Figura 6
Abbildung 6
E
D
A
B
C
H
G F
I
XTR402 XTR462 XTR522 XTR572 XTR602 XTR652 XTR693
Dimensions inches/mm, Dimensions pouces/mm, Dimensiones plg./mm, Abmessungen Zoll/
mm, Dimensioni pollici/millimetri, Dimensões polegadas/mm
A 1.89/48 1.89/48 2.28/58 2.17/55 1.75/44.5 2.01/51 3.23/82
B 0.79/20 0.75/19 0.91/23 0.79/20 0.91/23 0.83/21 1.18/30
C 2.76/70 2.56/65 2.76/70 3.11/79 2.76/70 3.15/80 3.94/100
D 4.06/102 4.72/120 5.20/132 5.04/128
E 5.04/128 5.79/147 6.36/161.5 6.30/160
F 3.66/93 4.96/126 5.79/147
G 4.10/104 5.52/140 6.46/164
H 6.11/155 7.17/182 8.43/214
I 6.11/155 8.67/220 9.25/235
