© 2008 directed electronics—all rights reserved 5
Wiring
Harness
Panel
Figure 3
Figura 3
Abbildung 3
Screws
Other Channel Source Unit
Amplifier
Cobalt Coaxial wired
to a single channel
Cobalt Coaxial wired
to a single channel
stereo
Figure 4
Figura 4
Abbildung 4
Figure 5
Figura 5
Abbildung 5
* The XTR speakers can be powered by a head unit or an amplifier.
* Les haut-parleurs XTR peuvent être alimentés par un récepteur ou un
amplificateur.
* Los altavoces XTR se pueden alimentar con una unidad principal o un
amplificador.
* Die XTR-Lautsprecher können von einem Autoradio oder einem Verstärker
betrieben werden.
* Gli altoparlanti XTR possono essere alimentati da una Head Unit o da un
amplificatore.
* Os alto-falantes de XTRo podem ser acionados por uma unidade principal ou
um amplificador.
