13 12
HT-R430
6.1-Channel A/V Surround Home Theatre Receiver
•100 W/Ch, continuous 8 Ω , 1 kHz, FTC •120 W/Ch, continuous
8 Ω , 1 kHz, JEITA •DTS ® -ES ™ Discrete/Matrix, DTS ® Neo:6, Dolby ®
Digital EX ™ , Dolby ® Pro Logic ® Ilx •192 kHz/24-bit DACs for all
channels •H.C.P.S. (High Current Power Supply) massive high power
transformer •WRAT (Wide Range Amplifier Technology)
•Advanced 32-bit processing DSP chip •OptiResponse
™ Equalizer
(OR-EQ ™ ) function •2 digital inputs (optical/coaxial)
•CinemaFILTER ™ •Subwoofer pre out •Optimum gain volume
circuitry •Color-coded 5.1 multichannel inputs •Speaker A/B
terminals •Double bass function •A-Form listening mode memory
•Dot matrix FL display •Color-coded speaker terminals •Crossover
adjustment (60/80/100/120/150 Hz) •RI (Remote Interactive)
remote control
HTP-430
6.1-Channel Home Theatre Speaker System
SKF-330F
2-Way Bass Reflex Front Speakers
•8 cm cone woofer •2 cm ceramic tweeter
•Magnetically shielded •Impedance: 8
Ω •Max. input
power: 100 W •Frequency response: 80 Hz–22 kHz
•WHD: 148 x 202 x 101 mm •0.9 kg
SKC-330C
2-Way Bass Reflex Center Speaker
•8 cm cone woofer x 2 •2 cm ceramic tweeter
•Magnetically shielded •Impedance: 8
Ω •Max. input
power: 100 W •Frequency response: 80 Hz–22 kHz
•WHD: 360 x 127 x 131 mm •1.6 kg
SKM-330S/SKB-330
2-Way Bass Reflex Surround/Surround Back
Speakers
•8 cm cone woofer •2 cm ceramic tweeter
•Impedance: 8
Ω •Max. input power: 100 W
•Frequency response: 80 Hz–22 kHz •WHD: 148 x
202 x 101 mm •0.7 kg
SKW-420
Bass Reflex Powered Subwoofer
•Built-in 150 W amplifier •Auto-standby/On circuitry
•20 cm cone woofer •Frequency response: 30 Hz–
150 Hz •WHD: 235 x 518 x 411 mm •12.8 kg
HT-S680
6.1-Channel A/V Surround Home Theatre Receiver/Speaker Package
HT-R530
7.1-Channel A/V Surround Home Theatre Receiver
•110 W/Ch, continuous 8 Ω , 1 kHz, FTC •130 W/Ch, continuous
8 Ω , 1 kHz, JEITA •DTS ® -ES ™ Discrete/Matrix, DTS ® Neo:6, DTS ®
96/24, Dolby ® Digital EX ™ , Dolby ® Pro Logic ® Ilx •192 kHz/24-bit
DACs for all channels •H.C.P.S. (High Current Power Supply)
massive high power transformer •HDTV-capable (50 MHz)
component video switching •WRAT (Wide Range Amplifier
Technology) •Advanced 32-bit processing DSP chip •3 wideband
component video inputs and 1 output •3 S-Video inputs and 2
outputs •4 digital inputs (3 optical/1 coaxial) •CinemaFILTER
™
•Subwoofer pre out •Optimum gain volume circuitry •Color-
coded 5.1 multichannel inputs •Speaker A/B terminals •Double
bass function •A-Form listening mode memory •OptiResponse
™
Equalizer (OR-EQ ™ ) function •Color-coded dual banana plug-
compatible speaker posts (except Speaker B) •Crossover
adjustment (60/80/100/120/150 Hz) •Preprogrammed RI (Remote
Interactive) remote control
HTP-530
7.1-Channel Home Theatre Speaker System
SKF-530F
2-Way Bass Reflex Front Speakers
•12 cm OMF diaphragm woofer x 2 •2.5 cm
balanced-dome tweeter •Magnetically shielded
•Impedance: 8
Ω •Max. input power: 110 W
•Frequency response: 55 Hz–50 kHz •WHD: 157 x
434 x 200 mm •3.9 kg
SKC-530C
2-Way Bass Reflex Center Speaker
•12 cm OMF diaphragm woofer x 2 •2.5 cm
balanced-dome tweeter •Magnetically shielded
•Impedance: 8
Ω •Max. input power: 110 W
•Frequency response: 55 Hz–50 kHz •WHD: 434 x
157 x 200 mm •3.9 kg
SKM-530S/SKB-530
2-Way Bass Reflex Surround/Surround Back
Speakers
•8 cm cone woofer •2 cm ceramic tweeter
•Impedance: 8
Ω •Max. input power: 110 W
•Frequency response: 60 Hz–20 kHz •WHD: 175 x
265 x 102 mm •1.4 kg
SKW-530
Bass Reflex Powered Subwoofer
•Built-in 230 W amplifier •Auto-standby/On circuitry
•25 cm cone woofer •Frequency response: 25 Hz–
150 Hz •WHD: 275 x 518 x 411 mm •13.6 kg
HT-S780
7.1-Channel A/V Surround Home Theatre Receiver/Speaker Package
BLACK SILVER
BLACK SILVER
BLACK SILVER
BLACK SILVER
Home Theatre Components 2005-2006 2005-2006 Home Theatre Systems
A vast divide separates playback components that offer nothing
more than the most basic video capabilities and those that
perform well with higher-grade systems.When you see and hear
the DV-SP303 DVD/CD/MP3 CD player, you’ll understand what is
possible by focusing on simple yet effective video-audio signal
processing. By incorporating an advanced 54 MHz/10-bit video
DAC and a 192 kHz/24-bit audio DAC, the DV-SP303 maintains
the quality of your signals—the ultimate goal of any playback
system.The DV-SP303’s strength lies in supporting playback not
only of DVD video, but also of DivX ® , CD audio and other digital
music formats. It even enables you to view your digital photos.
Designed to be admired as well as to perform—and sporting an
ultra-thin 6 cm profile—the DV-SP303 strikes a fine balance
between economy and better home theatre standards.
DV-SP303
DVD/CD/MP3 CD Player
• Plays DVDs, DVD-R/RWs, MP3 CDs,WMA CDs, CD-
R/RWs,Video CDs, Audio CDs and JPEG-Encoded CDs*
• DivX ® Video Playable
• PAL/NTSC Progressive Scan
• 192 kHz/24-Bit Audio DAC
• 54 MHz/10-Bit Video DAC
• Parallel Outputs—All Outputs Active
• Optical and Coaxial Digital Outputs
• 96 kHz or 48 kHz Selectable Digital Output
• Component Video, S-Video & Composite Video Outputs
• On-Screen Display (English/French/Spanish)
• Full-Function Remote Control
* Discs that have not been properly finalized may only be partially
playable or not playable at all.
If you like the notion of endless entertainment, then it’s a safe bet
that the DV-CP702 carousel changer will be an invaluable
entertainment partner.With its 6-disc capability, this DVD/CD/
MP3 CD player lets you play your own combinations of DVD
video discs, music CDs, MP3 CDs, as well as JPEG pictures of your
last holiday, family gathering or office party. Flick between each
format as you please with the DV-CP702’s RI (Remote Interactive)
remote control—you are in complete control of your
entertainment choices as well as your other components. Like all
other Onkyo playback components, the DV-CP702 incorporates
only the finest parts—like 192 kHz/24-bit audio DACs and a
54 MHz/10-bit video DAC—making this one of the most
technologically advanced carousel changers on the market.
DV-CP702
6-Disc DVD/CD/MP3 CD Carousel Changer
• Plays DVDs, DVD-R/RWs, MP3 CDs,WMA CDs, CD-R/RWs,
Video CDs, Audio CDs, and JPEG-Encoded CDs*
• 192 kHz/24-Bit Audio DACs
• 54 MHz/10-Bit Video DAC
• Direct Digital Path
• VLSC (Vector Linear Shaping Circuitry)
• Optical and Coaxial Digital Outputs
• Component Video, S-Video & Composite Video Outputs
• Ultra-Quiet Loading Mechanism
• Slim Design for Easy Placement
• Blue Light for Disc Recognition
• Program Playback and Memory
• On-Screen Display (English/French/Spanish)
• Passes PLUGE Signals
• Auto Dynamic Range Control
• 3-Level Display Dimmer (Normal/Dim/Dark)
• NTSC Progressive Scan
• Full-Function RI (Remote Interactive) Remote Control
* Discs that have not been properly finalized may only be partially
playable or not playable at all. Exclusive Mechanism
The DV-CP702’s exclusive design features a 6-disc
carousel with an ultra-quiet loading mechanism.
