Perfectly Packaging Cinema and Sound in Your Home
Combining universal playback capability with an ergonomic design
is no easy feat. The L-UN7 is ready for all your movies and
music—including high-resolution Super Audio CD and DVD-
Audio, as well as MP3 and WMA digital audio files. Unbelievably,
such a versatile system wouldn’t look out of place even in the
smaller rooms of your home. Naturally, audio quality’s also your
concern. WRAT (Wide Range Amplifier Technology), VLSC
(Vector Linear Shaping Circuitry) and our latest speaker
developments support a crystal-clear, nuanced sound rarely found
in compact entertainment systems.
DR-UN7, D-N7
CR-505, D-S7GX(W)
CR-305FX, D-N5FX
Bringing Audio Bliss into Your Home
CR-305FX
CD Receiver
Amplifier Features
•25 W/Ch, at 4 Ω , JEITA •WRAT (Wide Range Amplifier Technology) •Frequency response:
10 Hz–50 kHz (±3 dB) •High-current, low-impedance drive •Discrete output stage circuitry
•4-mode acoustic presence and super bass functions •2 audio inputs and 2 outputs
•Subwoofer pre out
CD Player Features
•Plays audio CDs, CD-R/RWs •Optical digital output •DLA Link2 (sets peak levels when one-
touch recording to an Onkyo MD/CD recorder) •20-track programming •4 play modes
(Track/Full/Random/Memory) •Repeat mode
Tuner & Other Features
•3 timer mode settings (Weekday/Weekend/Rec) •Sleep timer •30 FM/AM presets
•Automatic FM scan tuning •Usable sensitivity: 12.8 dBf, 1.0 µV (FM mono, 75
Ω , IHF)/30 µV
(AM) •Capture ratio: 2.0 dB (FM) •Image rejection ratio: 85 dB (FM)/40 dB (AM) •IF
rejection ratio: 90 dB (FM)/40 dB (AM) •S/N ratio: 73 dB (FM mono)/40 dB (AM) •Motor-
driven volume control •Battery-free memory backup •Headphone jack •Aluminum front
panel •Compatible with RI Dock for the iPod •Full-function RI (Remote Interactive) remote
control •WHD: 205 x 103 x 362 mm •4.0 kg
D-N5FX
2-Way Bass Reflex Speakers
•12 cm cone woofer •2.0 cm balanced-dome tweeter •Magnetically shielded •S-Line Edge
for responsive, hi-fidelity sound •Impedance: 5
Ω •Max. input power: 70 W •Frequency
response: 50 Hz–40 kHz •WHD: 147 x 253 x 250 mm •3.4 kg
CR-505
CD Receiver
Amplifier Features
•25 W/Ch, at 4 Ω , 1 kHz, JEITA •WRAT (Wide Range Amplifier Technology) •Frequency
response: 10 Hz–50 kHz (± 3 dB) •High-current, low-impedance drive •Discrete output stage
circuitry •Tone control (Bass/Treble) •Tone direct •3 audio inputs and 2 outputs
CD Player Features
•Plays audio CDs, MP3 CDs, CD-R/RWs •Optical digital output •20-track programming
•2 play modes (Random/Memory) •Repeat mode
An Elegant Blend of Quality and Style for When Space is at a Premium
CS-220
SILVER
Tuner & Other Features
•4 timer mode settings (Play or Rec/Once or Every) •Sleep timer •40 FM/AM presets
•Automatic FM scan tuning •Usable sensitivity: 12.8 dBf, 1.0 µV (FM mono, 75
Ω , IHF)/30 µV
(AM) •Capture ratio: 2.0 dB (FM) •Image rejection ratio: 85 dB (FM)/40 dB (AM) •IF
rejection ratio: 90 dB (FM)/40 dB (AM) •S/N ratio: 73 dB (FM mono) •Aluminum volume
knob •Battery-free memory backup •Headphone jack •Aluminum front panel •Compatible
with RI Dock for the iPod •Full-function RI (Remote Interactive) remote control •WHD: 205
x 103 x 356 mm •5.3 kg
D-S7GX(W)
2-Way Bass Reflex Loudspeakers
•12 cm A-OMF diaphragm woofer •2.5 cm soft-dome tweeter •Aero Acoustic Drive for
powerful and natural sound •Magnetically shielded •Impedance: 4
Ω •Max. input power:
70 W •Frequency response: 50 Hz–35 kHz •WHD: 158 x 267 x 244 mm •3.7 kg
CS-120
SILVER
2005-2006 Liverpool Mini Components
DR-UN7
Universal A/V Receiver
A/V Receiver Features
•26 W/Ch, at 4 Ω , 1 kHz, JEITA •DTS ® , Dolby ® Digital and Dolby ® Pro Logic ® II •VLSC
(Vector Linear Shaping Circuitry) •WRAT (Wide Range Amplifier Technology) •192 kHz/
24-bit DAC •32-bit processing DSP chip •High-current, low-impedance drive •Discrete
output stage circuitry •Optimum gain volume circuitry •Optical digital input •2 audio
inputs and 1 output •Tone control (Bass/Treble) •2-step super bass control •Center/
surround/subwoofer pre out
Universal Player Features
•Plays DVD-Audio and Video, DVD-R/RWs, Super Audio CDs, MP3 CDs, WMA CDs, CD-
R/RWs, video CDs, audio CDs, and JPEG-encoded CDs* •PAL/Auto progressive scan
•Component video output •Front virtual surround function (Theater Dimensional)
•24-track programming •2 play modes (Random/Memory) •2 repeat modes (Track/All)
* Discs that have not been properly finalized may only be partially playable or not playable at all.
Tuner & Other Features
•4 timer mode settings (Play or Rec/Once or Every) •Sleep timer •30 FM/AM presets
•Automatic FM scan tuning •Battery-free memory backup •Headphone jack •Aluminum
front panel •Compatible with RI Dock for the iPod •RI (Remote Interactive) remote
control •WHD: 205 x 147 x 353 mm •5.4 kg
D-N7
2-Way Bass Reflex Loudspeakers
•13 cm A-OMF diaphragm woofer •2.5 cm soft-dome tweeter •Aero Acoustic Drive for
powerful and natural sound •V-Line Edge to minimize unnecessary vibrations •MDF
cabinet •Frequency response: 55 Hz–35 kHz •Max input power: 70 W •WHD: 167 x
268 x 250 mm •4.0 kg
L-UN7
Universal A/V Receiver System
SILVER
