Advanced Operations
En-51
■
BD/DVD, CBL/SAT, STB/DVR, GAME, PC, TV/CD,
EXTRA1, EXTRA2
`
HDMI1, HDMI2, HDMI3, HDMI4, HDMI5,
HDMI6, HDMI7:
Select the input to which the component has been
connected.
`
- - - - -:
Output composite video and component video
sources from the HDMI output. The video output
signal from the HDMI output is the one configured in
“Component Video Input”.
Each HDMI input cannot be assigned to two input
selectors or more. When HDMI1 - HDMI7 have already
been assigned, you must first set any unused input
selectors to “- - - - -” or you will be unable to assign
HDMI1 - HDMI7 to other input selectors.
Tip
• “EXTRA1” and “EXTRA2” can be selected as input sources in
“Input” of “Quick Setup” (
).
Note
• If no video component is connected to HDMI output (even if the
HDMI input is assigned), the AV receiver selects the video
source based on the setting of “Component Video Input”.
• When an HDMI IN is assigned to an input selector as explained
here, the same HDMI IN will be set as a priority in the “Digital
Audio Input”. In this case, if you want to use the coaxial or
optical audio input, make the appropriate selection in the “Audio
Selector” setting (
).
• Do not assign an HDMI IN to the TV/CD selector while “HDMI
Control(RIHD)” is set to “On” (
), otherwise
appropriate CEC (Consumer Electronics Control) operation will
not be guaranteed.
• If you assign “- - - - -” to an input selector that is currently
selected in “HDMI Through” (
), the “HDMI
Through” setting will be automatically switched to “Off”.
• “AUX” is used only for input from the front panel.
Component Video Input
If you connect a video component to a component video
input, you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player to
COMPONENT VIDEO IN, you must assign “IN1” to the
“BD/DVD” input selector.
Here are the default assignments.
■
BD/DVD, CBL/SAT, STB/DVR, GAME, PC, TV/CD,
EXTRA1, EXTRA2
`
IN1:
Select the input to which the component has been
connected.
`
- - - - -:
Output composite video sources from the HDMI
output.
Tip
• “EXTRA1” and “EXTRA2” can be selected as input sources in
“Input” of “Quick Setup” (
Note
• When composite video and component video sources are
upconverted for HDMI OUT SUB, only signals with a resolution
of 480i are output and the resolution remains the same. If your TV
doesn’t support this resolution, there will be no picture
(
).
• “AUX” is fixed to the “- - - - -” option.
Digital Audio Input
If you connect a component to a digital audio input, you
must assign that input to an input selector. For example, if
you connect your CD player to the OPTICAL IN 1, you
must assign “OPTICAL1” to the “TV/CD” input selector.
Here are the default assignments.
■
BD/DVD, CBL/SAT, STB/DVR, GAME, PC, TV/CD,
EXTRA1, EXTRA2
`
COAXIAL1, COAXIAL2, OPTICAL1,
OPTICAL2:
Select the input to which the component has been
connected.
`
- - - - -:
Select if the component is connected to an analog
audio input.
Tip
• “EXTRA1” and “EXTRA2” can be selected as input sources in
“Input” of “Quick Setup” (
Note
• When an HDMI IN is assigned to an input selector in
“HDMI Input” (
), the same HDMI IN will be set as
a priority in this assignment. In this case, if you want to use the
coaxial or optical audio input, make the appropriate selection in
the “Audio Selector” (
• Supported sampling rates for PCM signals (stereo/mono) from a
digital input (optical and coaxial) are 32/44.1/48/88.2/96 kHz/16,
20, 24 bit.
• “AUX” is fixed to the “- - - - -” option.
Input selector
Default assignment
BD/DVD
- - - - -
CBL/SAT
IN1
STB/DVR
- - - - -
GAME
- - - - -
PC
- - - - -
AUX
- - - - - (Fixed)
TV/CD
- - - - -
EXTRA1
- - - - -
EXTRA2
- - - - -
Input selector
Default assignment
BD/DVD
COAXIAL1
CBL/SAT
COAXIAL2
STB/DVR
- - - - -
GAME
OPTICAL1
PC
- - - - -
AUX
- - - - - (Fixed)
TV/CD
OPTICAL2
EXTRA1
- - - - -
EXTRA2
- - - - -
