Appendix
En-76
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
Rated Output Power
All channels:
(North American)
80 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.7% (FTC)
130 watts minimum continuous power per
channel, 6 ohm loads, 1 channels driven at
1 kHz, with a maximum total harmonic
distortion of 1% (FTC)
(Others)
5 ch × 130 W at 6 ohms, 1 kHz, 1 ch driven
of 1% (IEC)
Maximum Effective Output Power
(Asian)
5 ch × 160 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power *
* IEC60268-Short-term maximum output power
180 W (3 Ω, Front)
160 W (4 Ω, Front)
100 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 k Ω (LINE)
Rated RCA Output Level and Impedance
200 mV/2.2 k Ω (LINE OUT)
Maximum RCA Output Level and Impedance
2 V/2.2 k Ω (LINE OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (DSP bypass)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component P
B /C B , P R /C R )
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
FM Tuning Frequency Range
(North American) 87.5 MHz - 107.9 MHz
(Taiwanese) 87.5 MHz - 108.0 MHz
(Others) 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply (North American and Taiwanese)
AC 120 V, 60 Hz
(European and Australian)
AC 230 V, 50 Hz
(Others) AC 220 - 240 V, 50/60 Hz
Power Consumption (North American and Taiwanese) 4.2 A
(European and Australian) 400 W
(Others) 450 W
No-sound Power Consumption
(North American, European, Australian
and Taiwanese)
55 W
(Others)
55 W (230 V)
60 W (240 V)
Stand-by Power Consumption
(North American) 0.1 W
(Others) 0.2 W
Dimensions (W × H × D)
435 mm × 173.5 mm × 328 mm
17-1/8" Ч 6-13/16" Ч 12-15/16"
Weight (North American and Taiwanese)
8.6 kg (19.0 lbs.)
(European and Australian)
9.0 kg (19.8 lbs.)
(Others)
9.4 kg (20.7 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6
Output OUT
Video Resolution 1080p
Audio Format Dolby True HD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, LipSync, CEC (RIHD)
Component IN 1, IN 2
Composite BD/DVD, CBL/SAT, GAME, PC, AUX
To be continued
