69
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Rated Output Power
All channels:
110 watts minimum continuous power per channel, 6 ohm
loads, at 1kHz with a maximum total harmonic distortion of
1 %
Maximum Output Power
Asian (JEITA): 1 ch
×
120 W at 6 ohms, 1 kHz, 1ch driven
Dynamic Power 160 W (3
Ω, Front)
125 W (4
Ω, Front)
85 W (8
Ω, Front)
THD (Total Harmonic Distortion)
0.08% (1kHz, 1 W)
Damping Factor 60 (Front, 1kHz, 8
Ω)
Input Sensitivity and Impedance
200 mV/ 47 k
Ω (LINE)
Output Level and Impedance
200 mV/ 470
Ω (REC OUT)
Frequency Response 20Hz–50kHz/ +1 dB–3 dB (Direct)
Tone Control ±10 dB, 50Hz (BASS)
±10 dB, 20kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6
Ω–16Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p /75
Ω (Component Y)
0.7 Vp-p /75
Ω (Component Pb/Cb, Pr/Cr)
1 Vp-p /75
Ω (Composite)
Component Video Frequency Response
5Hz – 50MHz, –3 dB
FM Tuning Frequency Range
North American: 87.5MHz–107.9MHz
Asian: 87.5MHz–108.0MHz
AM Tuning Frequency Range
North American: 530kHz–1710kHz at 10 kHz steps
Asian: 522 kHz–1611 kHz at 9 kHz steps
530 kHz–1710 kHz at 10 kHz steps
Preset Channel 40
Power Supply
North American: AC 120 V, 60Hz
Asian: AC 220-240 V, 50/60Hz
Power Consumption
North American: 3.4 A
Asian: 440 W
Dimensions
(W
×
H
×
D)
435
Ч
151.5
Ч
329 mm
17-1/8"
Ч
5-15/16"
Ч
12-15/16"
Weight
North American: 8.0 kg
17.6 lbs.
Asian: 9.1 kg
20.1 lbs.
HDMI IN 1, IN 2, IN 3
Component IN 1, IN 2
Composite CBL/SAT, VCR/DVR, DVD/BD
HDMI OUT
Component OUT
Composite VCR/DVR (REC OUT),
MONITOR OUT
Digital Inputs COAXIAL:1
OPTICAL :2
Analog Inputs CD, TV/TAPE, CBL/SAT, VCR/DVR,
DVD/BD, AUX
Analog Outputs TV/TAPE, VCR/DVR
Speaker Outputs SP-A (L, R), C, SL, SR, SW + SP-B (L, R)
Phones 1
