9

Specifications

Supply voltage:

8 V to 30 V dc, protected against reversed
polarity.

Supply protection:

0.5 A fuse

Supply connection:

Minimum requirement either:
24 AWG single-strand wire.
or
7/0.2 multi-strand wire.

Current consumption:

70 mA maximum, with fully loaded talker ports.

Inputs:

4 x NMEA-183, galvanically isolated.

Input resistance:

>800 Ohm.

Outputs:

1 x NMEA-183.

Buffers:

2 buffers of 1000 characters (NMEA In 3 and
NMEA In 4 only).

NMEA Out:

Combined data from NMEA inputs.

Speed NMEA in:

4800 baud.

Speed NMEA out:

4800 baud.

Indicators:

Overflow and Data LEDs.

Dimensions:

138 x 72 x 33 mm.

Housing:

Flame retardant ABS.
