WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
Repair Parts
16 U.S. Gallons Wet/Dry Vac With Detachable Blower
Model Number WD16650
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
16
Key
No. Part No. Description
23 818961 Spacer
24 822459-1 Collector Gasket
25 828979 Foam Holder Asm
26 822480 Blowing Diffuser
27 822482 Male-Male Adapter
28 826404 Motor/Collection
(Includes Key Nos.
20 thru 23)
29 826830 Motor Cover
30 823871 Switch Rocker
31 829718-3 Cord Asm
32 826388 Latch Powerhead
33 VT2509 Utility Nozzle
34 VT2503 Car Nozzle
35 VT2506 Blower Nozzle
36 VT2510 Wet Nozzle
37 822256 Squeegee
38 VT2508 Extension Wands
39 815096 Adapter Hose
40 826356-1 Hose Locking 2-1/2” x 7’
(Includes Key Nos.
39, 41 & 42)
41 826355-1 Spring Tab
42 826354 End Hose Interlock
43 SP6438 Owners Manual
Key
No.
Part No. Description
1 509488 Float
2 823201-1 Filter Cage
3 VF4000 Filter
4 73317 Filter Plate
5 73316 Filter Nut
6 829755 Drum w/Handles
7 85881-2 Drain Cap
8 828833 Caster Foot w/Storage
9 73102 Caster
10 828843 Caddy Accessory
11 826387 Drum Latch
12 826832 Lid
13 826833 Handle Pull
14 820563-7 Screw Pan Hd Ty
AB #10 x 3/4
15 822442-1 Gasket Lid
16 826383-2 Intake Shield
17 826411 Foam Pad
18 826389 Holder Foam Pad
19 826871 Lid Detachable
(Includes Key Nos.
16, 17, & 18)
20 73352 Nut-Hex Flange 1/4-20
21 15534-1 Washer
22 818413 Blower Wheel
* Standard Hardware Item - May Be Purchased Locally
† These replacement parts are available where you purchased your vac.
†
