Section 1 Configuration
CAUTION
Use an IC149-100-054-B51 socket (manufactured by
YAMAICHI ELECTRONICS Co., Ltd.) for the FP-100B/TFP-
100B package IC socket on the user system.
Figure 1 shows the configuration of the HS2318ECH61H user system interface cable for the
FP-100B/TFP-100B package.
Figure 1 HS2318ECH61H User System Interface Cable
1
