Renesas M3T-F160-64NSA - Manual (Page 5)

(3/4)
5. External Dimensions and a Sample Foot Pattern
55.0 21.8
40
.0
5.
3
16.
5
40
a
40
b
1a 1b
40
21
20 1
41 60
61
80
40
a
40
b
1a 1b
CN1 CN2 ………
…
………
…
… …
… …
0.5
0.8
17.2
13.2
17
.2
13
.2
M3T-F160-64NSA REV.A
MADE IN JAPAN
I C1
Figure 3 External dimensions and a sample foot pattern of the M3T-F160-64NSA
6. Precautions
CAUTION
Caution to Be Taken for This Product:
z When connecting the YQPACK064SA, be sure to use the included YQ-GUIDE's.
z Do NOT use the screws included with the YQPACK064SA for connecting the YQPACK064SA.
IMPORTANT
Notes on This Product:
z We cannot accept any request for repair.
z For purchasing the NQPACK064SA160, YQPACK064SA, HQPACK064SA160, contact the following:
Tokyo Eletech Corporation http://www.tetc.co.jp/e_tet.htm
z For inquiries about the product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage http://www.renesas.com/en/tools
