Figure 4.3 Inserting MCU (IC socket: QFP type)
4.3 Inserting MCU into Programming Adapter
As shown in Figures 4.2 and 4.3, insert the No. 1 pin of the MCU into the No. 1 pin of the IC socket
on the main unit.
Be careful when inserting the MCU because incorrect insertion can cause fatal
damage to the MCU.
Figure 4.2 Inserting MCU (IC socket: DIP type)
Top view
Top view
