Renesas Converter Board M3T-F160-80NSD - Manual (Page 3)

(3/4)
5. External Dimensions and a Sample Foot Pattern
55.0 21.8
40
.0
5.
3
16.
5
40
a
40
b
1a 1b
40
21
20 1
41 60
61
80
40
a
40
b
1a 1b
CN1 CN2
0.25
0.5
15.1
11.1
15.
1
11
.1
M3T-F160-80NSD REV.A
MADE IN JAPAN
I C1
Figure 3 External dimensions and a sample foot pattern of the M3T-F160-80NSD
6. Precautions
CAUTION
Caution to Be Taken for This Product:
z When connecting the YQPACK080SD, be sure to use the included YQ-GUIDE's.
z Do NOT use the screws included with the YQPACK080SD for connecting the YQPACK080SD.
IMPORTANT
Notes on This Product:
z We cannot accept any request for repair.
z For purchasing the NQPACK080SD-ND, YQPACK080SD, HQPACK080SD, contact the following:
Tokyo Eletech Corporation http://www.tetc.co.jp/e_tet.htm
Daimaru Kogyo Ltd. http://www.daimarukogyo.co.jp/
z For inquiries about the product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage http://www.renesas.com/en/tools
