CAUTION
Cautions to Be Taken for Emulator:
• When debugging, use this product in the combination with the M32170T-SDI or
M32100T-SDI-E emulator.
• When starting up emulator debugger PD32R, select the MCU file below according
to the type name and the operation mode of the MCU to be debugged.
7. Precautions
Cautions to Be Taken for This Product:
• When connecting the YQPACK240SD, be sure to use the included YQ-GUIDE's.
• We cannot accept any request for repair.
• For purchasing the NQPACK240SD, YQPACK240SD and HQPACK240SD, contact
the following:
Daimaru Kogyo Ltd.
URL: http://www.daimaru-kogyo.com/
Tokyo Eletech Corporation
URL: http://www.tetc.co.jp/e_tet.htm
• For inquiries about the product or the contents of this manual, contact your local
distributor.
Renesas Tools Homepage http://www.renesas.com/en/tools
Cautions for Differences between MCU and this Product:
• When debugging, as the M32170F6VWG (768KB internal flash ROM) on the
M32170T-PTC is used, be careful about the difference of the flash ROM size.
• When setting to the clock select switch to the "EXT" side, connect the clock
generated by the oscillator on the target board etc. to the XIN pin. The oscillation by
the oscillator on the target board between the XIN and XOUT does not occur.
• The capacity load of the all lines of the MCU will increase depending on wirings and
connectors. Use the part whose timing is critical after checking it works properly.
MCU type name Single-chip and memory expansion modes Microprocessor mode
M32170F3VFP M32170F3PTC_MCU.MCU M32170F3PTC_MPU.MCU
M32170F4VFP M32170F4PTC_MCU.MCU M32170F4PTC_MPU.MCU
M32170F6VFP M32170F6VWG_MCU.MCU M32170F6VWG_MPU.MCU
• Connect the both cables for connecting the emulator, the SDI MCU control interface
cable (10-pin) and the SDI trace interface cable (20-pin).
• For the precautions for the combination of the emulator, refer to the user's manuals
of the M32170T-SDI or M32100T-SDI-E.
